Cable Routing Engineering
3D Modelling & Database
Historically, raceway filling has been largely governed by guesswork and approximation. Without 3D modelling, cabling project costs can be overestimated or underestimated by up to 30% because of the inaccuracy of manual routing methods (including spreadsheet use) — leading to significant overspend on design, installation, and material costs, particularly on large projects where spreadsheet data becomes unmanageable.
Elecdes ManPower offers 3D modelling and engineering services of cable routing and cable tray filling conforming to NEC and other fill rules. The scope of cable modelling services we provide includes:
- Managing cables in a database
- Raceway network design checking
- Automatic cable routing
- Automatic tray fill calculations
- Transit filling calculation and configuration
- Showing cable routes in 3D models
- Cable tray and Transit 2D cross-sectional drawings
- Bottleneck identification on the cable routes and network
- Consolidated reports of cable routes, cable fill, transit fill, centre of gravity, redundant cable routing, and issued and pulled cable tracking
Achieving 98% accuracy in cable length and raceway fill calculations, delivering significant savings on design, installation, and material costs.
SCADA System Development
Supervisory control and data acquisition is one of our specialties. We can "turnkey" provide man-machine and networking systems to suit your plant or wide area application. The choice of software and hardware is flexible and we offer full projects or labour only services.
Systems are priced on a specification basis.
PLC-DCS Programming
Scada Systems can provide the expertise to supply, program and commission PLC and DCS based systems for your plant. We handle a diverse range of applications such as manufacturing systems, processing systems, batch systems, continuous systems, conveying systems, wide area systems, mobile and offshore systems.
Target Hardware options:
- Siemens
- Square D
- Modicon
- Telemecanique
- Omron
- Allen Bradley
- Yokogawa
- Bailey
- Honeywell
